SURFACE SEDIMENTS AT THE SUBAQUEOUS YELLOW RIVER DELTA: CLASSIFICATION AND DISTRIBUTION
-
摘要: 基于近期在黄河三角洲附近海域采集的97个表层沉积物样品的粒度测试结果,研究了黄河三角洲海域表层沉积物的类型和空间分布特征,探讨了沉积物粒度分布特征与物源和沉积动力环境之间的关系。研究结果表明,研究区表层沉积物类型以砂质粉砂和粉砂为主,在绝大部分海域,表层沉积物的偏态表现为正偏和极正偏,分选程度较差,峰态表现为宽和很宽。现行河口三角洲叶瓣周围的表层沉积物以砂质粉砂为主,粒度较粗;而在远离河口的区域表层沉积物以粉砂为主,粒度较细。与20世纪80年代的观测结果相比,受物源供应和沉积环境的共同影响,近期黄河三角洲沿岸的表层沉积物有粗化的趋势,且河口口门区域表层沉积物粗化趋势最为明显。表层沉积物粒度粗化的主要原因是黄河入海泥沙供应不足,导致三角洲沿岸侵蚀加剧;黄河调水调沙以来入海泥沙的粒度变粗,粗颗粒组分在河口口门附近快速堆积。黄河水下三角洲现代沉积速率的分布特征表明,黄河入海沉积物主要在现行河口及三角洲的近岸区域沉积,在15 m以深的区域沉积速率较低。同时,还可看出入海泥沙有向北和东北向的运移趋势,与渤海中部泥质沉积以及通过莱州湾向渤海海峡的泥沙输运相对应。粗颗粒沉积物在现行河口三角洲叶瓣的堆积范围与潮流切变锋的位置基本一致,反映了物源供应和沉积动力环境对研究区表层沉积物分布特征的控制性影响。Abstract: Based on the grain-size analysis of surface sediments recently sampled at the subaqueous Yellow River Delta, the classification and spatial distribution of the surface sediment are presented. The results indicate that the surface sediments at the subaqueous Yellow River Delta are primarily composed of sandy silt and silt, mostly characterized by positive to strongly positive skewness, relatively poor in sorting, and wide to very wide kurtosis. The surface sediments around the presently active delta lobe are mostly sandy silt, relatively coarse in grain size, whereas the surface sediments are relatively fine-grained in offshore area away from the present river mouth. Compared with the investigation in 1980s, the recent surface sediments at the subaqueous Yellow River Delta seem to be coarser in grain size. The significant changes might be attributed to the enhanced erosion along the delta coast due to insufficient sediment supply from the Yellow River. Meanwhile, the sediment delivered from the river to the sea has been much coarser since the Water-Sediment Regulation in 2002, which resulted in considerable accumulation of coarser sediments around the present river mouth. The distribution of sedimentation rate at the subaqueous Yellow River Delta indicates that the river-delivered sediments are mostly accumulated at the present river mouth and along the delta coast, together with northward and northeastward transport corresponding to the accumulation of fine-grained sediment in the central Bohai Sea and sediment export to the Bohai Strait through the Laizhou Bay, respectively. In addition, the high accumulation rate of coarse-grained sediments around the present river mouth implies the trapping effects from the tide-induced shear front. Our results indicate that both sediment supply and sedimentary dynamic environment play predominant roles in the distribution of surface sediments at the subaqueous Yellow River Delta.
-
Keywords:
- surface sediments /
- grain size /
- sediment supply /
- sedimentary environment /
- Yellow River Delta
-
-
[1] Wang L, Sarnthein M, Erlenkeuser H, et al. East Asian monsoon climate during the Late Pleistocene:high-resolution sediment records from the South China Sea[J]. Marine Geology, 1999, 156(1-4):245-284.
[2] Xiao S B, Li A C, Liu J P, et al. Coherence between solar activity and the East Asian winter monsoon variability in the past 8000 years from Yangtze River-derived mud in the East China Sea[J]. Palaeogeography, Palaeoclimatology, Palaeoecology, 2006, 237(2-4):293-304.
[3] 徐东浩,李军,赵京涛,等. 辽东湾表层沉积物粒度分布特征及其地质意义[J]. 海洋地质与第四纪地质, 2012, 32(5):35-42. [XU Donghao, LI Jun, ZHAO Jingtao, et al. Grain-size distribution of surface sediments of the Liaodong Bay, Bohai and sedimentary environment restoration[J]. Marine Geology and Quaternary Geology, 2012, 32(5):35-42.]
[4] 杨旭辉,冯秀丽,褚忠信,等. 中国东部陆架表层沉积物粒度特征及其沉积环境浅析[J]. 中国海洋大学学报:自然科学版, 2012, 42(7-8):126 -134.[YANG Xuhui, FENG Xiuli, CHU Zhongxin, et al. Surface sediment distribution and sedimentary environment on the East China continental shelf[J]. Periodical of Ocean University of China, 2012, 42(7-8):126-134.]
[5] Mclaren P, Bowles D. The effects of sediment transport on grain-size distributions[J]. Journal of Sedimentary Petrology, 1985, 55(4):457-470.
[6] 贾建军,高抒,薛允传. 图解法与矩法沉积物粒度参数的对比[J]. 海洋与湖沼, 2002, 33(6):577-582. [JIA Jianjun, GAO Shu, XUE Yunchuan. Grain-size parameters derived from graphic and moment methods:a comparative study[J]. Oceanologia et Limnologia Sinica, 2002, 33(6):577-582.]
[7] 王伟,李安春,徐方建,等. 北黄海表层沉积物粒度分布特征及其沉积环境分析[J]. 海洋与湖沼, 2009, 40(5):525-531. [WANG Wei, LI Anchun, XU Fangjian, et al. Distribution of surface sediments and sedimentary environment in the north Yellow Sea[J]. Oceanologia et Limnologia Sinica, 2009, 40(5):525-531.]
[8] Wang H J, Bi N S, Saito Y, et al. Recent changes in sediment delivery by the Huanghe (Yellow River) to the sea:Causes and environmental implications in its estuary[J]. Journal of Hydrology, 2010, 391(3-4):302-313.
[9] Wu X, Bi N S, Kanai Y, et al. Sedimentary records off the modern Huanghe (Yellow River) delta and their response to deltaic river channel shifts over the last 200 years[J]. Journal of Asian Earth Sciences, 2015, 108:68-80.
[10] Wang H J, Wang A M, Bi N S, et al. Seasonal distribution of suspended sediment in the Bohai Sea, China[J]. Continental Shelf Research, 2014, 90:17-32.
[11] 秦蕴珊,赵松龄,赵一阳,等. 渤海地质[M]. 北京:科学出版社, 1985.[QIN Yunshan, ZHAO Songling, ZHAO Yiyang, et al. Geology of the Bohai Sea[M]. Beijing:Science Press, 1985.] [12] Bi N S, Wang H J, Yang Z S. Recent changes in the erosion-accretion patterns of the active Huanghe (Yellow River) delta lobe caused by human activities[J]. Continental Shelf Research, 2014, 90:70-78.
[13] Li G X, Tang Z S, Yue S H, et al. Sedimentation in the shear front off the Yellow River mouth[J]. Continental Shelf Research, 2001, 21(6-7):607-625.
[14] Wang H J, Yang Z S, Li Y H, et al. Dispersal pattern of suspended sediment in the shear frontal zone off the Huanghe (Yellow River) mouth[J]. Continental Shelf Research, 2007, 27(6):854-871.
[15] 贾永刚,单红仙,杨秀娟,等. 黄河口沉积物动力学与地质灾害[M]. 北京:科学出版社, 2011.[JIA Yonggang, SHAN Hongxian, YANG Xiujuan, et al. Sediment Dynamics and Geologic Hazards in the Estuary of Yellow River, China[M]. Beijing:Science Press, 2011.] [16] 胡春宏,吉祖稳,王涛. 黄河口海洋动力特性与泥沙的输移扩散[J]. 泥沙研究, 1996(4):1-10.[HU Chunhong, JI Zuwen, WANG Tao. Characteristics of ocean dynamics and sediment diffusion in the Yellow River estuary[J]. Journal of Sediment Research, 1996 (4):1-10.]
[17] 庞家珍,姜明星. 黄河河口演变(I)-(一)河口水文特征[J]. 海洋湖沼通报, 2003(3):1-13.[PANG Jiazhen, JIANG Mingxing. On the evolution of the Yellow River estuary(I)-I. Hydrographic characteristics[J]. Transactions of Oceanology and Limnology, 2003 (3):1-13.]
[18] Wentworth C K. A scale of grade and class terms for clastic sediments[J]. Journal of Geology, 1922, 30(5):377-392.
[19] Shepard F P. Nomenclature based on sand-silt-clay ratios[J]. Journal of Sedimentary Geology, 1954, 24(3):151-158.
[20] Mcmanus J. Grain size determination and interpretation[M]//In:Tucker, M. (ed.), Techniques in Sedimentology. Oxford:Wiley Backwell, 1988:63-85.
[21] Wang H J, Yang Z S, Saito Y, et al. Stepwise decreases of the Huanghe (Yellow River) sediment load (1950-2005):Impacts of climate change and human activities[J]. Global and Planetary Change, 2007, 57(3-4):331-354.
[22] Wang H J, Yang Z S, Li G X, et al. Wave Climate Modeling on the Abandoned Huanghe (Yellow River) Delta Lobe and Related Deltaic Erosion[J]. Journal of Coastal Research, 2006, 22(4):906-918.
[23] Wang H J, Saito Y, Zhang Y, et al. Recent changes of sediment flux to the western Pacific Ocean from major rivers in East and Southeast Asia[J]. Earth-Science Reviews, 2011, 108(1-2):80-100.
[24] Yang Z S, Ji Y J, Bi N S, et al. Sediment transport off the Huanghe (Yellow River) delta and in the adjacent Bohai Sea in winter and seasonal comparison[J]. Estuarine Coastal and Shelf Science, 2011, 93(3):173-181.
[25] 任韧希子,陈沈良. 黄河下游至三角洲滨海区表层沉积物分异特征和规律[J]. 海洋科学进展, 2010, 28(1):24-31. [REN Renxizi, CHEN Shenliang. The differentiation of bottom sediments from the downstream of the Yellow River to the delta nearshore area[J]. Advances in Marine Science, 2010, 28(1):24-31.]
[26] 刘风岳,高明德. 黄河口烂泥湾的特征及其开发[J]. 海洋科学, 1986, 10(1):20-23. [LIU Fengyue, GAO Mingde. The characteristics and exploitation of the mud bay at the Yellow River estuary[J]. Marine Sciences, 1986, 10(1):20-23.]
[27] 毕乃双. 黄河三角洲毗邻海域悬浮泥沙扩散和季节性变化及冲淤效应[D]. 中国海洋大学博士论文, 2009.[BI Naishuang. Suspended sediment dispersal off the Huanghe(Yellow River) delta and in its adjacent Bohai Sea, its seasonal variation and effect on the delta erosion-accumulation[D]. Doctoral dissertation, Ocean University of China, 2009.] [28] 高佳,陈学恩,于华明,等. 黄河口海域潮汐、潮流、余流、切变锋数值模拟[J]. 中国海洋大学学报:自然科学版, 2010, 40(S1):41-48. [GAO Jia, CHEN Xueen, YU Huaming, et al. Numerical simulation of tides, tidal currents, residual currents and shear front in estuary[J]. Periodical of Ocean University of China, 2010, 40(S1):41-48.]
[29] 李广雪,成国栋,魏合龙,等. 现代黄河口区流场切变带[J]. 科学通报, 1994(10):928-932.[LI Guangxue, CHENG Guodong, WEI Helong, et al. The area of shear flow near the modern Yellow River estuary[J]. Chinese Science Bulletin, 1994 (10):928-932.]
[30] Bi N S, Yang Z S, Wang H J, et al. Sediment dispersion pattern off the present Huanghe (Yellow River) subdelta and its dynamic mechanism during normal river discharge period[J]. Estuarine, Coastal and Shelf Science, 2010, 86(3):352-362.
[31] 杜瑞芝,刘国贤,杨松林,等. 渤海湾现代沉积速率和沉积过程[J]. 海洋地质与第四纪地质, 1990, 10(3):15-22. [DU Ruizhi, LIU Guoxian, YANG Songlin, et al. Modern sedimentation rate and sedimentation process in Bohai Bay[J]. Marine Geology and Quaternary Geology, 1990, 10(3):15-22.]
[32] 杨松林,刘国贤,杜瑞芝,等. 莱州湾及渤海中央盆地南部海域沉积速率的研究[J]. 海洋学报, 1991, 13(6):804-812. [YANG Songlin, LIU Guoxian, DU Ruizhi, et al. Research on sedimentation rate in the Laizhou Bay and southern part of central basin of the Bohai Sea[J]. Acta Oceanologica Sinica, 1991, 13(6):804-812.]
[33] Li F Y. Modern Sedimentation Rates and Sedimentation Feature in the Huanghe River Estuary based on 210Pb Technique[J]. Chinese Journal of Oceanology and Limnology, 1993, 11(4):333-342.
[34] 李凤业,史玉兰. 渤海南部现代沉积物堆积速率和沉积环境[J]. 黄渤海海洋, 1995, 13(2):33-37. [LI Fengye, SHI Yulan. Accumulation rates of sediment and sedimentary environment in the south Bohai Sea[J]. Journal of Oceanography of Huanghai and Bohai Seas, 1995, 13(2):33-37.]
[35] 董太禄,扬光复,徐善民. 渤海南部现代沉积特征[J]. 海洋地质与第四纪地质, 1995, 15(4):131-134. [DONG Tailu, YANG Guangfu, XU Shanmin. Modern sedimentary characteristics in the south of the Bohai Sea[J]. Marine Geology and Quaternary Geology, 1995, 15(4):131-134.]
[36] 胡邦琦,李国刚,李军,等. 黄海、渤海210Pb沉积速率的分布特征及其影响因素[J]. 海洋学报, 2011, 33(6):125-133. [HU Bangqi, LI Guogang, LI Jun, et al. Spatial variability of the 210Pb sedimentation rates in the Bohai and Huanghai Seas and its influencing factors[J]. Acta Oceanologica Sinica, 2011, 33(6):125-133.]
[37] 李军,胡邦琦,窦衍光,等. 中国东部海域泥质沉积区现代沉积速率及其物源控制效应初探[J]. 地质论评, 2012, 58(4):745-756. [LI Jun, HU Bangqi, DOU Yanguang, et al. Modern sedimentation rate, budget and supply of the muddy deposits in the East China Seas[J]. Geological Review, 2012, 58(4):745-756.]
-
